OM-CP-RHTEMP1000記錄儀 美國omega

濕度和溫度數據記錄器，NOMAD?系列成員
OM-CP-RHTEMP1000
5年保修 CE
濕度和溫度數據記錄器，NOMAD?系列成員
OM-CP-RHTEMP1000:濕度和溫度數據記錄器，NOMAD?系列成員
OM-CP-RHTEMP1000
實時操作
通過軟件用戶校準
露點/蒸氣濃度的計算
在軟件
這OM-CP-RHTEMP1000濕度和溫度數據記錄儀是一種防水（溫度測量），電池供電，獨立的裝置，用于自動記錄溫度從40到80°C.這個一體化的緊湊，便攜，易于使用的設備可以測量并記錄溫度高達10920和10920的濕度測量。提出的OM-CP-RHTEMP1000在尺寸和性能的重大飛躍。實時時鐘確保所有數據的時間和日期戳。存儲介質是非易失性固態存儲器，提供**大的數據安全，即使電池已出院。它的小尺寸使得它幾乎可以滿足任何地方。數據檢索是簡單的。插入一個空的COM端口和使用Windows軟件的易做休息。該軟件將你的電腦變成一個真正的時間的長條圖表記錄儀。數據可以打印表格的格式，也可以導出到一個文本或微軟Excel文件。

規格：
TEMPERATURE CHANNEL PERFORMANCE
Temperature Sensor:Semiconductor
Temperature Measurement Range:
-40 to 80°C (-40 to 176°F)1
Temperature Resolution: 0.1°C
Calibrated Accuracy: +0.5°C
Specified Accuracy Range: 0 to 50°C
HUMIDITY CHANNEL PERFORMANCE
Humidity Sensor: Solid state semiconductor 4,5
Humidity Measurement Range: 0 to ** RH
Humidity Resolution: 0.5% RH
Calibrated Accuracy:
+3%RH (+2 %RH typical at 25°C)
Specified Accuracy Range:
10 to 80% RH; 10 to 40°C (50 to 104°F)2,3
Humdiity Response Time:
90% of change in 60 seconds in slow moving air
General Specifications
Readings: 21,845 readings/channel Temperature/Humidity
Calibration: Digital calibration is available through software
Calibration Date: Automatically recorded within device
Recording Interval: 30/minute to day selectable through software
Start Time: start time and date are programmable
through software, up to 6 months in advance
Real Time Recording: Device may be used with PC
to monitor and record data in real time
Power: 3.6 V lithium battery included
Time Accuracy: ±1 minute per month at 20°C, RS-232 port not in use
Data Format: Date and time stamped,
°C, °F, °K, °R %RH, mg of water vapor concentration,
Weight:
Aluminum: 145 g (5 oz)
Stainless steel: 285 g (10 oz)
Computer Interface: PC serial, RS-232C COM
or USB (interface cable required)
Software: XP SP3/Vista and 7 (32-bit and 64-bit)
Operating Environment:
-40 to 80°C (-40 to 176°F)
0 to ** RH non-condensing when case is properly sealed
Dimensions:
25 mm dia x 137 mm L
(1.00 x 5.40")
Material: aluminum or stainless steel
